Tellyard

A live TV tuner you'll forget is running.

tellyard.sandobserver.com

Tellyard presents itself to Plex and Jellyfin as an HDHomeRun network tuner. You list your channels in one file. When a viewer tunes in, Tellyard finds the channel's current stream, picks its best quality and hands it over without re-encoding. When the viewer leaves, it stops. Nothing is downloaded while nobody watches, and it runs as one small container with no database.

What you get

• On demand. A stream runs only while someone watches, and up to TUNERS at once.
• YouTube, Twitch, web players and HLS. Live channels on YouTube, Twitch, Kick and other sites through yt-dlp, broadcaster pages that embed an HLS playlist, and direct HLS playlists. The stream is found again on every tune, so expiring links never break playback.
• A guide that is never empty. Real schedules from any XMLTV source, with placeholder blocks in every gap. Shows are filed as TV episodes, with a category.
• Tries to reconnect. A stalled or dropped source is restarted on its own, up to three tries in a row.
• Quality check. tellyard check tunes each channel and reports the resolution it really sends, so a channel below your minimum never slips in.
• One file. Channels live in channels.toml, reloaded while Tellyard runs.

Getting started

You need Docker on a 64-bit Intel, AMD or ARM machine, and Plex or Jellyfin. Watching live TV is free; recording in Plex needs Plex Pass.

1. Write your channel list

Create a config folder and copy channels.example.toml into it as channels.toml. Replace the examples with your channels. See Channels.

2. Create the compose file

Save this as compose.yml next to the config folder.

services:
  tellyard:
    image: ghcr.io/sandobserver/tellyard:latest
    container_name: tellyard
    restart: unless-stopped
    init: true
    read_only: true
    tmpfs:
      - /tmp
    cap_drop:
      - ALL
    security_opt:
      - no-new-privileges:true
    mem_limit: 512m
    environment:
      # Time zone for log timestamps
      - TZ=America/New_York
      # Streams that may play at the same time
      - TUNERS=4
      # Lowest resolution `tellyard check` accepts: off, or a height such as 1080
      - MIN_HEIGHT=off
    volumes:
      - ./config:/config:ro
      - ./data:/data
    ports:
      - "5004:5004"

./data is where Tellyard caches the guide and the yt-dlp files between restarts.

Tellyard has no login. Anyone who can reach port 5004 can start streams, so keep it on your home network and do not forward the port to the internet. See Security.

3. Start it

In the folder with compose.yml:

mkdir -p ./data && sudo chown 1000:1000 ./data
docker compose up -d

Tellyard runs as user 1000 and writes only to ./data and /tmp.

mkdir -p ./data && sudo chown 1000:1000 ./data
docker run -d --name tellyard --restart unless-stopped \
  --init --read-only --tmpfs /tmp --cap-drop ALL \
  --security-opt no-new-privileges:true --memory 512m \
  -e TZ=America/New_York -e TUNERS=4 -e MIN_HEIGHT=off \
  -v ./config:/config:ro -v ./data:/data -p 5004:5004 \
  ghcr.io/sandobserver/tellyard:latest

4. Check your channels

docker exec tellyard tellyard check

This tunes each channel once and reports the resolution it really sends. Fix or remove any channel that fails before adding Tellyard to Plex.

5. Add it to your media server

Tellyard does not announce itself on the network, so enter its address by hand: your server's address with port 5004, for example 192.168.1.10:5004. Its guide is http://192.168.1.10:5004/guide.xml.

• Plex: Settings > Live TV & DVR > Set up Plex DVR. Enter the address, then choose Have an XMLTV guide on your server? Click here to use it and enter the guide address. On an iPhone, iPad or Apple TV, turn on Force Direct Play in the Plex app. See Plex.
• Jellyfin: Dashboard > Live TV. Add a tuner device of type HDHomeRun with the address, then add an XMLTV guide provider with the guide address.

Unraid

Open Apps, search for Tellyard and choose Install. It starts with no channels. Put your list in place from the Unraid terminal, starting from the example:

curl -fsSL -o /mnt/user/appdata/tellyard/config/channels.toml \
  https://raw.githubusercontent.com/SandObserver/Tellyard/main/channels.example.toml
nano /mnt/user/appdata/tellyard/config/channels.toml

Tellyard loads the file within a minute. Check the channels with docker exec Tellyard tellyard check (on Unraid the container is named Tellyard), then add it to your media server as in step 5, with your Unraid server's address. The template runs as Unraid's nobody user (--user=99:100) with the same lockdown as the compose file, and restarts the container after a crash.

If Apps does not list Tellyard yet, save the template from the Unraid terminal, then pick Tellyard under Docker, Add Container, Template:

curl -fsSL -o /boot/config/plugins/dockerMan/templates-user/my-Tellyard.xml \
  https://raw.githubusercontent.com/SandObserver/Tellyard/main/templates/tellyard.xml

Channels

Each channel in channels.toml needs a number, a name, a logo and one source:

[[channel]]
number = 101
name = "Example News"
logo = "https://example.com/logos/example-news.png"
hls = "https://example.com/live/news/master.m3u8"
[channel.guide]
category = "News"

Channels lists every option and how to find sources, logos and guides. Tellyard reloads the file within a minute of a change and keeps the previous channels if the new file has a mistake. After adding or removing channels, refresh the guide in Plex.

Only add streams you are allowed to watch.

Commands

Run a command inside the container:

docker exec tellyard tellyard check

Settings

Set these as environment variables.

Documentation

• Channels: every option, finding sources, guides and logos.
• Plex: adding Tellyard, refreshing the guide, and settings for the Plex apps.
• How it works: tuning, reconnects, the guide and the HTTP endpoints.
• Troubleshooting: log messages and what to do.
• Upgrade, back up, uninstall

Contributing

See CONTRIBUTING.md for setup, checks and releases. Changes are listed in CHANGELOG.md.

Legal

Tellyard is an independent project. It is not affiliated with or endorsed by Plex, SiliconDust (HDHomeRun), YouTube, Twitch, Kick or any broadcaster. Their names appear only to say what Tellyard works with.

Tellyard ships no channels, stream addresses or logos. It plays only the sources you list. It contains no code to decrypt DRM or to get around logins, paywalls or region limits. You are responsible for making sure you may watch each source you add and that your use follows its terms.

License

Apache License 2.0. See NOTICE for the name and the third-party software in the container image.
