Deploying mcpelevator on Unraid

mcpelevator runs as a single Docker container on Unraid and turns your server into a self-hosted hub for MCP servers: add a server in the web UI, press start, and point MCP clients on your LAN at http://<unraid-ip>:8080/s/<slug>/mcp. (Claude web/mobile connectors dial from Anthropic's cloud, not your device — they need the tunnel recipe in Exposing beyond your LAN below; locally-dialing clients like Claude Code, Claude Desktop, VS Code, and Gemini CLI work with the LAN URL directly.)

The published image is multi-arch (amd64 + arm64) and batteries-included — Node/npx and Python/uv are preinstalled, so npx/uvx MCP servers run with zero extra setup.

• Image: ghcr.io/pacnpal/mcpelevator:latest
• Template: mcpelevator.xml in pacnpal/unraid-templates

Install

Option A — Community Applications

Search for mcpelevator in the Apps tab and click Install. The template defaults are the recommended setup; review them against the table below and hit Apply.

Option B — manual template (before/without CA listing)

Unraid 6.10 removed the old "Template repositories" field, so place the XML on the flash drive yourself:

1. From a terminal on the box (SSH or the web terminal), download the template into dockerMan's user-templates folder:

   curl -fL -o /boot/config/plugins/dockerMan/templates-user/my-mcpelevator.xml \
     https://raw.githubusercontent.com/pacnpal/unraid-templates/main/mcpelevator.xml


2. Go to Docker → Add Container and pick mcpelevator from the Template dropdown (under User templates).

3. Review the settings against the table below and Apply.

Recommended settings (what the template does and why)

Turning LAN access on automatically turns control-plane auth on, so /api (and the web UI) require an admin token — see the next section.

First login: grab the admin token from the logs

Because LAN access enables control-plane auth, mcpelevator mints an admin token on first start and prints it once to the container logs. It is stored only as a hash, so this is your one chance to copy it:

1. Start the container.

2. Open the container log (click the mcpelevator icon → Logs).

3. Look for the block:

   ================================================================
     mcpelevator control-plane auth is ON.
     Admin token (shown once, store it now):  <token>
   ================================================================


4. Open http://<unraid-ip>:8080, paste the token into the login screen, and store it in your password manager.

Lost the token? Two recovery hatches, both via container env vars (edit the container, add the variable, restart):

• MCPE_ADMIN_TOKEN=<your-secret> — a break-glass token that is always accepted on /api. Set it, log in, generate a fresh token in Settings, then remove the var.
• MCPE_MINT_ADMIN_TOKEN=true — mints a new token on boot and prints it to the logs (existing tokens keep working). Unset it after grabbing the token, or you'll mint another one on every restart.

Using it

1. Open the web UI, Add server (guided form, paste an mcpServers JSON config, or Browse a registry and one-click install).
2. Start it, then use the per-client copy menu on the server page — it has ready-made snippets for Claude Code, Claude Desktop (via mcp-remote), VS Code, Gemini CLI, and more, already pointing at http://<unraid-ip>:8080/s/<slug>/mcp. The Claude web/mobile connector snippets need a public HTTPS URL to be usable — those connectors are dialed from Anthropic's cloud, so set up a tunnel first (see Exposing beyond your LAN).
3. For anything reachable off-host, put a bearer token on the server (Auth → bearer) so the endpoint isn't open to everyone on your network.

Per-server setup

The npx, uvx, and command runners can have an optional setup script. It runs through /bin/sh -e -c before every startup attempt, with the MCP child's initial environment and working directory. Each retry runs it again, so keep it safe to rerun. Files remain where the script writes them, but export, cd, and aliases do not carry into the child. Docker setup belongs in the image, and remote servers have no local setup.

The script is plain server configuration, and its output goes to the authenticated server logs. Treat both as sensitive. The official container currently runs as root, so its setup scripts do too. Only /data and any other paths you explicitly mount survive a container replacement; the npm and uv caches survive because they are configured under /data. Use MCPE_APT_PACKAGES for global Debian packages needed by every server, not as a per-server setup script. Those packages are installed again after container replacement.

Setup and readiness each receive their own MCPE_START_TIMEOUT_S window per attempt. Failed setup, bridge launch or readiness, and exits before a stable run retry the whole attempt after 2, 4, 8, then 16 seconds, capped at 16. The default budget is 5 attempts. After 60 seconds of uninterrupted running the budget resets. Stop cancels startup or a pending retry. An enabled server that ends in Failed or Unhealthy can be retried from the UI without changing its configuration, or with POST /api/servers/{id}/retry.

Docker runner (opt-in, root-equivalent)

mcpelevator can also run MCP servers packaged as Docker images (e.g. ghcr.io/github/github-mcp-server). This is OFF by default and root-equivalent: it launches images on a Docker daemon, and anything that can reach the Docker socket is effectively root on the host. Only enable it if you trust every image you run.

To turn it on in the template (both steps are required):

1. Set Docker Runner (root-equivalent) (MCPE_DOCKER_RUNNER) to true. This seeds the docker_runner setting on first boot; the Settings toggle is authoritative afterwards.
2. Add the Docker socket mount manually — in the container's edit page click Add another Path, Port, Variable, Label or Device, choose Path, and set both Container Path and Host Path to /var/run/docker.sock. This is the sibling-container model: launched images talk to Unraid's own Docker daemon. (The template deliberately doesn't ship this mount — an empty socket path would generate an invalid bind and fail the container for everyone.)

Once enabled, paste an mcpServers docker config (e.g. docker run … <image>) or install an OCI catalog entry, then start it like any other server. mcpelevator stores the canonical shape and synthesizes a hardened docker run (--rm --init --cap-drop ALL --security-opt no-new-privileges --pids-limit + a memory cap, secrets passed by name, and a label it uses to reap orphaned containers). Import surfaces a warning for any docker run option it drops (host mounts, --network, --env-file, --platform, …).

Stronger isolation: instead of the host socket, run a separate docker:dind daemon and point mcpelevator at it with DOCKER_HOST — launched images then never touch Unraid's own daemon. Security: a plaintext tcp://…:2375 endpoint is unauthenticated — anyone who can reach it controls that daemon (root-equivalent). Only use 2375 on a strictly private, non-routable Docker network shared by just these two containers, and never publish or port-forward it. For anything less contained, front dind with TLS on 2376 (DOCKER_HOST=tcp://<dind-host>:2376 + DOCKER_TLS_VERIFY=1 and certs). See the project's docker-compose.yml and docs/security.md for the full model and both isolation options.

Updating

The template tracks ghcr.io/pacnpal/mcpelevator:latest. Unraid's built-in update check (Docker → Check for Updates) picks up new releases; apply the update and the reconciler restarts your enabled servers automatically. Pin a specific version by changing the repository tag (e.g. ghcr.io/pacnpal/mcpelevator:1.1.0) — published tags are listed on the GHCR package page.

Backup

Everything lives in the appdata share: /mnt/user/appdata/mcpelevator. The SQLite database (mcpelevator.db) holds servers, settings, and token hashes; .npm-cache / .uv-cache are safely regenerable. The CA Appdata Backup plugin covers it.

If you switch to bridge networking

It works, with one caveat: Docker's port publishing masquerades every client to the bridge gateway IP (a private address), so the LAN gate can no longer distinguish a LAN client from a forwarded public one. You are then leaning entirely on the control-plane admin token and per-server bearer auth — which allow_private_lan requires anyway, but keep it in mind before port-forwarding anything. Map the container port (8080) to a host port as usual; leave MCPE_PORT at 8080 and remap on the host side instead.

Exposing beyond your LAN

Don't port-forward the raw port. To reach the box from outside (e.g. Claude web/mobile away from home), use a tunnel that terminates auth — see claude-web-exposure.md for three concrete recipes (Cloudflare Tunnel + Access with Managed OAuth, a public HTTPS tunnel + mcpelevator's built-in bearer auth, or mcpelevator's OAuth resource server with your own authorization server). Set MCPE_PUBLIC_BASE_URL to the tunnel URL so the copy menu hands out the right addresses.

Environment variables (template reference)

The full list, including reverse-proxy knobs (MCPE_TRUSTED_PROXIES, MCPE_TRUST_DOCKER_HOST), is in the README.

Troubleshooting

• 403 on http://<unraid-ip>:8080 — LAN access is off (or the request isn't coming from a private-network peer). Check the container log for the auth banner; verify MCPE_ALLOW_PRIVATE_LAN=true was set on first boot, or toggle Allow access from devices on your local network in Settings via a loopback path (SSH tunnel: ssh -L 8080:127.0.0.1:8080 root@<unraid-ip>, then http://localhost:8080 — substitute your MCPE_PORT for both 8080s if you changed it). Only private-IP-literal hosts qualify — a hostname that resolves to a LAN IP is rejected by design; add such a hostname via MCPE_ALLOWED_HOSTS instead.
• Login screen but no token — the token is printed only when it's first minted. Scroll the log back to the first start, or use one of the recovery env vars above.
• Port already in use — host networking means a real bind conflict; change MCPE_PORT in the template.
• A server is slow to start the first time — npx/uvx download the package on first run. The cache persists in /data, so subsequent starts are fast. Raise MCPE_START_TIMEOUT_S for very large setup scripts or packages; setup and readiness each receive the full timeout.
