KaraokeDock

A modern, full-featured web-based karaoke system with support for multiple media formats, real-time queue management, and external karaoke integration.

Table of Contents

• Features
• Web Pages Overview
• Quick Start with Docker
• First-Time Setup
• Architecture
• Development
• Troubleshooting

Overview

KaraokeDock started because none of the apps out there really fit the way I wanted to run a show. I wanted something that gave me full control without forcing me to stand there all night acting as the DJ/KJ. The goal was to make hosting feel easier, more flexible, and less tied to one specific machine, setup, or location.

I also wanted a platform that could run anywhere, on almost anything, while still supporting the collection I’ve built over time. Just as important, I wanted it to work alongside the awesome creations the karaoke community has already made. KaraokeDock brings that together with local library playback, external song sources, and live queue syncing between the host, player, and singer request pages.

Recent platform updates add:

• 🔐 Library Browse Added browse tab to request page
• 🔐 OIDC/SSO authentication with auto-provisioning options, role defaults, and optional password-login fallback
• 🔄 Advanced rotation engine with multiple rotation types (strict round robin, least recently sung, signup order, song-queue-only, manual, and hybrid) plus host overrides
• 🎶 Break music management with playlists, active playlist sync, volume control, and crossfade settings between karaoke tracks
• 🖥️ Player/overlay controls for QR visibility, ticker controls, queue privacy options, and live settings propagation over WebSocket

✨ Features

• 🎤 Multi-format support: MP4 videos, CDG+MP3 files (raw and zipped)
• 🔄 Real-time queue updates via WebSocket
• 📱 Mobile-friendly interface with QR code for easy guest access
• 🌐 External karaoke integration (Karaoke Nerds)
• ⚡ Auto-play mode with configurable delays
• 🎚️ Configurable rotation policies with host controls
• 🎶 Break music playlists with crossfade and live controls
• 🎵 CDG to MP4 streaming transcoding on-the-fly
• 🔐 Flexible authentication: local sessions + OIDC/SSO
• 📊 Admin dashboard for library management and statistics
• 🎯 Host panel for queue control and playback management

Web Pages Overview

Requests Page

URL: http://your-server:5173/

The main interface for guests to browse and request songs. Fully mobile-responsive and accessible via QR code.

Functions:

• Search local karaoke library
• Browse songs by title or artist
• Filter results with advanced options
• Submit song requests with your name
• Switch to Karaoke Nerds for online songs

Karaoke Nerds Integration

URL: http://your-server:5173/ (switch to Karaoke Nerds tab)

Access thousands of online karaoke tracks from Karaoke Nerds directly within the app.

Functions:

• Search online karaoke catalog
• Preview and add external songs
• Seamless integration with your queue
• No need to download files

Host Panel

URL: http://your-server:5173/host

The control center for managing the karaoke session.

Functions:

• View real-time queue updates
• Play, skip, and stop songs
• Manage queue order (reorder, remove songs)
• Enable auto-play mode
• Manually add songs to the queue

Manage break music

Configure playback settings

Player Page

URL: http://your-server:5173/player

Full-screen karaoke player optimized for display on TVs or projectors.

Functions:

• Full-screen video playback
• Display current song information
• Show scrolling text when idle
• QR code display for song requests
• Automatic queue progression

Admin Dashboard

URL: http://your-server:5173/admin

Management interface for system configuration and media libraries.

Functions:

• View system statistics (artists, tracks, queue)
• Add and manage media libraries
• Add and manage break music
• Scan directories for karaoke files & break music
• User manager
• OIDC/SSO settings

Quick Start with Docker

Prerequisites

• A Linux machine or WSL that can run Docker
• Karaoke media files (MP4, CDG+MP3, or ZIP files) - optional

Installation Steps

1. Install Docker and the Docker Compose plugin.

   Follow the official Docker installation guide for your platform:

   • Docker Engine
   • Docker Compose plugin

   Confirm both are available:

   docker --version
   docker compose version


2. Create a karaokedock folder for your deployment files:

   mkdir -p ~/karaokedock
   cd ~/karaokedock


3. Download or copy KaraokeDock's docker-compose.yml and .env.example into the karaokedock folder.

   Download them directly:

   curl -o docker-compose.yml https://raw.githubusercontent.com/haggardj2/KaraokeDock/refs/heads/main/docker-compose.yml
   curl -o .env.example https://raw.githubusercontent.com/haggardj2/KaraokeDock/refs/heads/main/.env.example


   Or copy them from a local checkout:

   cp /path/to/KaraokeDock/docker-compose.yml .
   cp /path/to/KaraokeDock/.env.example .


4. Create .env from the new environment file:

   cp .env.example .env


5. Edit .env with your host paths and network settings:

   nano .env


   At minimum, review and update these values from .env.example:

   POSTGRES_PASSWORD=karaoke
   DB_PATH=/home/user/karaokedock/db
   APP_PORT=5173
   MEDIA_ROOT=/media
   KARAOKE_PATH=/mnt/karaoke/Karaoke Tracks
   DOWNLOADS_PATH=/mnt/karaoke/downloads
   BREAKMUSIC_PATH=/mnt/karaoke/Break Music
   WEB_APP_URL=http://localhost:5173
   ORIGIN=http://localhost:5173,http://127.0.0.1:5173
   DB_PORT=5432
   TRUST_PROXY=1


   KaraokeDock serves the web app and API from the same container on port 5173. To change the exposed host ports, update APP_PORT and DB_PORT.

6. Create the host directories you configured if they do not already exist:

   mkdir -p /home/user/karaokedock/db
   mkdir -p /mnt/karaoke/downloads


7. Start the stack with docker-compose.yml:

   docker compose -f docker-compose.yml up -d


8. Check container status:

   docker compose -f docker-compose.yml ps


   You should see two running containers:

   • karaokedock (KaraokeDock app)
   • karaokedock-db (PostgreSQL Database)

9. Access the application:

   • Web Interface: http://your-server:5173
   • Admin Panel: http://your-server:5173/admin
   • Host Panel: http://your-server:5173/host
   • Player: http://your-server:5173/player

Managing the Application

View logs:

# All services
docker compose logs -f

# Specific service
docker compose logs -f karaokedock
docker compose logs -f karaokedock-db

Stop the application:

docker compose down

Update to latest version:

docker compose pull
docker compose up -d

Restart services:

docker compose restart

Build locally (development):

docker build -f dev/Dockerfile -t haggardj2/karaokedock:latest .
docker compose -f docker-compose.yml up -d

Configuration

Environment Variables

All configuration is managed through the .env file. Key variables:

Important Notes:

• Replace your-server-ip with your server's IP address for network access
• Ensure ORIGIN includes every URL where the app will be opened
• KARAOKE_PATH, DOWNLOADS_PATH, and BREAKMUSIC_PATH map to /media/karaoke, /media/downloads, and /media/breakmusic
• Change APP_PORT / DB_PORT to remap host ports
• Change default passwords before deploying to production

If your container platform exposes environment variables more cleanly than full connection strings, the app can instead derive its database connection from DB_HOST, DB_PORT, DB_NAME, DB_USER, and DB_PASSWORD. In that mode, DB_PORT is the database service port inside the app container, usually 5432. If you are running PostgreSQL as a separate container, DB_HOST must be a hostname the app container can actually resolve on a shared network. For Unraid custom networks, the container must join that network with --network=<name> in Extra Parameters; setting the XML <Network> field to the custom name is not enough. The Docker Compose setup in this repo still uses DATABASE_URL, so existing installs do not need to change.

Network Configuration

To access from other devices on your network:

1. Set WEB_APP_URL to your server's IP: http://your-server-ip:5173
2. Update ORIGIN to include your server's IP
3. Ensure firewall allows port 5173

To setup reverse proxy for SSL termination:

1. Set WEB_APP_URL to your FQDN: https://karaoke.example.com
2. Update ORIGIN to include that public URL
3. Set TRUST_PROXY=1 when running behind the proxy
4. Point the proxy to the app container on port 5173

First-Time Setup

After starting the containers for the first time:

1. Navigate to the Admin page:

   http://your-server:5173/admin


2. Get the bootstrap admin password:

   • Username: admin
   • Password: check the app container logs from the first boot:

     docker compose logs karaokedock


3. ⚠️ Change the bootstrap password immediately after logging in

4. Add a media library:

   • Click "Add Library"
   • Name: Give it a descriptive name (e.g., "My Karaoke Collection")
   • Path: Enter /media/karaoke (this is the container path, not your host path)
   • Click "Add Library"

5. Scan your files:

   • Click "Scan All Libraries"
   • Wait for the scan to complete
   • Refresh stats to see your track count

6. Access the Host panel:

   • Go to http://your-server:5173/host
   • Login with your password

7. Open a player window

   • Open a browser tab to http://your-server-ip:5173/player
   • If serving from an Android TV, you can use a kiosk browser app

8. Done! Guests can now request songs via the Requests page

Troubleshooting

Common Issues

QR code shows localhost instead of server IP:

• Solution: Set WEB_APP_URL in .env to your server's IP address

Cannot connect to API from other devices:

• Solution: Set WEB_APP_URL and ORIGIN to your server's IP or public URL
• Check firewall allows port 5173

CORS errors in browser console:

• Solution: Add your access URL to ORIGIN in .env

No songs appearing after scan:

• Check KARAOKE_PATH points to the correct host directory
• Verify files are in supported formats
• Check app logs: docker compose logs karaokedock

Database connection errors:

• Wait 10-15 seconds for database to initialize on first start
• Restart the stack: docker compose restart karaokedock karaokedock-db

Permission denied errors:

• Ensure media files are readable by Docker
• On Linux with SELinux, the :Z flag in volumes may help

Forgot Login

# Run password reset helper:
docker exec -it karaokedock npm run reset-credentials
# Defaults to username "admin" and generates a secure password if --password is omitted.
docker exec -it karaokedock npm run reset-credentials -- --password supersecret
# Or set a specific username/password:
docker exec -it karaokedock npm run reset-credentials -- --username admin --password supersecret

Reenable Password Login

# Run the re-enable-login helper
docker exec -it karaokedock npm run re-enable-login

Docker Compose Architecture

The application runs two Docker containers:

----------------------     ------------------
|     karaokedock     |     | karaokedock-db |
|   (Web + API App)   |---> |  (PostgreSQL)  |
|     Port: 5173      |     |   Port: 5432   |
----------------------     ------------------

Container Details:

• karaokedock: Combined React frontend + Node.js/Express backend

  • Image: haggardj2/karaokedock:latest
  • Exposed port: 5173
  • Mounts:
    • KARAOKE_PATH → /media/karaoke
    • DOWNLOADS_PATH → /media/downloads
    • BREAKMUSIC_PATH → /media/breakmusic

• karaokedock-db: PostgreSQL 18 database

  • Image: postgres:18
  • Exposed port: 5432

Architecture

Technology Stack

Frontend:

• React 19 with TypeScript
• Vite for development and building
• React Router for navigation
• WebSocket for real-time updates

Backend:

• Node.js with Express
• TypeScript for type safety
• PostgreSQL for data persistence
• WebSocket for live queue sync
• Recompiled FFmpeg with rubberband for pitch adjustment
• FFmpeg for CDG to MP4 transcoding

Infrastructure:

• Docker for containerization
• Docker Compose for orchestration
• Pre-built images hosted on Docker Hub

Supported File Formats

• MP4 videos: Direct playback
• CDG+MP3 pairs: Transcoded to MP4 on-the-fly
• ZIP archives: Automatically extracted and processed
• Break Music: mp3,flac,opus,wav
• External URLs: From Karaoke Nerds and similar services

Data Flow

1. Media files scanned and indexed into PostgreSQL
2. Guests request songs via Requests page
3. Queue updates broadcast via WebSocket
4. Host controls playback from Host panel
5. Player page displays current song
6. CDG files transcoded to MP4 in real-time if needed

Development

Local Development (without Docker)

Server:

cd src/server
npm install
cp ../../.env.example .env
# Edit .env with local settings
npm run migrate
npm run dev

Web:

cd src/web
npm install
npm run dev

Database:

# Start PostgreSQL in Docker
docker run -d \
  --name karaokedock-db \
  -e POSTGRES_DB=karaoke \
  -e POSTGRES_USER=karaoke \
  -e POSTGRES_PASSWORD=karaoke \
  -p 5432:5432 \
  postgres:18-alpine

Building Docker Images

To build the KaraokeDock image locally:

docker build -f dev/Dockerfile -t haggardj2/karaokedock:latest .

Viewing Logs

# Specific container
docker compose logs -f karaokedock
docker compose logs -f karaokedock-db

Security Considerations

• Change default passwords immediately after first login
• Change database password in production environments
• Use HTTPS with a reverse proxy (nginx, Traefik) for production
• Keep Docker images updated: docker compose pull
• Restrict network access to admin and host pages if needed

License

See LICENSE file for details.

Contributing

Contributions are welcome! Please feel free to submit issues or pull requests.

Support

For issues and questions:

• Open an issue on GitHub
• Check existing documentation in the repository
• Review Docker logs for error messages

Docker Images:

• KaraokeDock app: haggardj2/karaokedock:latest
• Database base image: postgres:18-alpine
