docker-hdhomerundvr

Docker container for the HDHomeRun DVR Server by SiliconDust.

HDHomeRun DVR Server version: 20250815
Base image: debian:bookworm-slim

Features

• Runs the HDHomeRun DVR recording engine inside a Docker container
• entrypoint.sh keeps the process alive — auto-restarts if the DVR daemon crashes (up to 10 retries)
• Container-level restart: unless-stopped policy recovers from container failures
• Minimal image (no Python/supervisord) — the DVR daemon runs as an unprivileged user via setpriv
• Timezone configurable via the TZ environment variable
• Host networking for full HDHomeRun device discovery (UDP broadcast)

Requirements

• A working HDHomeRun network tuner with up-to-date firmware (see below)
• Docker and Docker Compose installed on the host

Quick Start

Option A: Docker Hub

Use the published image from Docker Hub:

https://hub.docker.com/repository/docker/yoshiofthewire/hdhomerundvr/general

Option B: Build Locally

# 1. Clone the repository
git clone https://github.com/Yoshiofthewire/docker-hdhomerundvr.git
cd docker-hdhomerundvr

# 2. Edit docker-compose.yml and set your recordings path and timezone
#    volumes:
#      - /your/recordings/path:/hdhomerun
#    environment:
#      - TZ=America/New_York

# 3. Build and start
docker compose up -d --build

Configuration

Environment Variables

Volumes

Ports

Note: network_mode: host is used in docker-compose.yml so that UDP broadcast device discovery works correctly. In host mode, the ports mapping is bypassed, so the ports above are documentation only.

Updating the HDHomeRun Firmware

Before the first install or when updating firmware:

1. Install the HDHomeRun Windows or Mac application.
2. When prompted to install the DVR server component, select Don't Install.
3. You will be prompted to configure the tuner after setup completes.
4. Re-run the tuner setup — this will update the firmware.
5. You may need to re-scan channels after the firmware update.

CI / Release Workflow

This repository includes a GitHub Actions workflow at .github/workflows/docker-release.yml.

On each push to main or manual dispatch, the workflow:

• computes an auto-incrementing release version from the Git commit count
• builds the Docker image
• tags and pushes the image to Docker Hub
• creates a Git tag like v1.0.<commit_count>
• creates a GitHub release for the tag

To allow Docker image publishing, configure these repository secrets:

• DOCKERHUB_USERNAME
• DOCKERHUB_TOKEN

The built image is published as:

• docker.io/yoshiofthewire/hdhomerundvr:1.0.<commit_count>
• docker.io/yoshiofthewire/hdhomerundvr:latest

How It Works

flowchart TD
    A[Docker container] --> B[entrypoint.sh\nPID 1]
    B --> C[setpriv drops to hdhomerun user\nruns hdhomerun_wrapper.sh]
    C --> D[hdhomerun_record_x64 start\nStarts DVR daemon]
    C --> E[Monitors DVR process\nevery 15 seconds]
    E --> F[If the DVR process disappears, the wrapper exits non-zero]
    F --> G[entrypoint.sh restarts the wrapper\nup to 10 retries]
    H[SIGTERM from Docker] --> I[entrypoint.sh forwards TERM to the wrapper,\nwhich calls hdhomerun_record_x64 stop]

• entrypoint.sh runs as PID 1 in the foreground, preventing spurious container exits.
• It uses setpriv to drop from root to the unprivileged hdhomerun user before running hdhomerun_wrapper.sh, which wraps the DVR daemon (which forks to the background) and stays alive to monitor it.
• If the DVR process disappears, the wrapper exits with a non-zero code so entrypoint.sh restarts it (up to 10 retries).
• SIGTERM from Docker is caught cleanly by entrypoint.sh, which forwards it to the wrapper — the wrapper calls hdhomerun_record_x64 stop before exiting.

License

GPL v2.0
