🌩️ CloudGate

Self-hosted WebUI for Cloudflare Tunnels and playit.gg. Host services from behind CGNAT without port forwarding — Immich, Nextcloud, Jellyfin, Proxmox, Home Assistant, you name it.

Status: stable — v0.5.0 is the first production-ready release.

Why CloudGate?

Many home internet connections (especially in Germany — 1&1, Vodafone Cable, mobile) sit behind CGNAT or DS-Lite. You have no public IPv4, no port forwarding, and tools like Nginx Proxy Manager simply don't work.

Cloudflare Tunnel solves this — for free — but the setup (cloudflared login, tunnel create, route dns, manage config.yml, run the daemon) is a hard wall for non-sysadmins.

CloudGate is a WebUI that does it all:

• Add a service: enter 192.168.1.42:8080 and immich.yourdomain.com → done.
• CloudGate creates the Cloudflare Tunnel, DNS record, ingress rule, and reloads cloudflared.
• Need raw TCP/UDP instead of HTTP — a Minecraft server, SSH, a game server? Playit.gg tunnels handle that (Cloudflare's free tier can't).
• Hybrid mode: per host, pick "via Cloudflare Tunnel" OR "local nginx reverse proxy".
• Self-updates when new releases ship on a standalone install — never overwrites your data. On an app-store install, the platform updates the image instead (see Install from an app store).

Not affiliated with Cloudflare or Playit.gg. CloudGate uses their public, documented APIs.

Quick Start

Option A — One-liner (Ubuntu / Debian / LXC / Proxmox)

Fresh Ubuntu container, no prior setup:

bash -c "$(curl -fsSL https://raw.githubusercontent.com/Elias02345/CloudGate/main/install/lxc-install.sh)"

The installer:

• Installs Docker if missing
• Pulls the latest CloudGate image (falls back to building from source)
• Creates a persistent data volume
• Starts the container and waits for it to become healthy
• Prints your initial admin password

Re-runnable — running it again won't wipe your data.

Proxmox LXC users: enable nesting=1,keyctl=1 in the container's features config. Use an Ubuntu 24.04 template, 2 cores, 1 GB RAM, 4 GB disk minimum.

Option B — Plain Docker

If you already have Docker:

docker run -d --name cloudgate \
  -p 80:80 -p 443:443 \
  -v cloudgate-data:/data \
  --restart unless-stopped \
  ghcr.io/elias02345/cloudgate:latest

The admin UI/API is also served on port 8080 (-p 8080:8080) — the port app-store platforms (Umbrel, TrueNAS, Unraid, ZimaOS) publish on their own. 80/443 are only needed if you use CloudGate's local-nginx reverse-proxy mode.

What happens next

1. Open http://<your-host-ip>/ (or port 8080) in a browser.
2. Login as admin@cloudgate.local with the password shown in container logs:

   docker logs cloudgate | grep -A1 "INITIAL ADMIN PASSWORD"


3. Change the password (forced on first login).
4. Add your Cloudflare API token in the UI (instructions: see docs/CLOUDFLARE_SETUP.md).
5. Create your first tunnel, add a host — services live within ~30 seconds.

That's it. CloudGate manages keys, secrets, and updates automatically.

Install from an app store

Packages for Unraid, TrueNAS, Umbrel and ZimaOS are prepared in packaging/ and listings are pending review with each store — CloudGate isn't listed in any app store yet. Once accepted, an app-store install publishes only the admin port and leaves updates to the platform (CLOUDGATE_DISABLE_UPDATES=true); see docs/STORE_PUBLISHING.md for details.

Features

Architecture

┌────────────────────────────────────────────────────────────────┐
│  Browser ──http→ nginx :8080 (and :80) ──┬─→ React SPA (static) │
│                                          └─→ /api → backend :3000│
└────────────────────────────────────────────────────────────────┘
                                  │
        ┌─────────────────────────┴───────────────────────────┐
        │  CloudGate container (s6-overlay supervised)        │
        │                                                     │
        │  bootstrap (oneshot, idempotent) ─► success ─► main │
        │                                  └─► failure ─► recovery-ui
        │                                                     │
        │  backend  ┌──► spawns cloudflared ──tunnels──→ CF   │
        │           ├──► spawns playit-agent ──tunnels──→ Playit.gg
        │           ├──► writes /data/cloudflared/config.yml  │
        │           ├──► writes /data/nginx/hosts/*.conf      │
        │           ├──► self-updater (GitHub polling)        │
        │           └──► ACME cert renewal cron               │
        └─────────────────────────────────────────────────────┘
                                  │
              ┌───────────────────┴───────────────────┐
              │  /data volume — sacred                 │
              │  secrets/  db/  cloudflared/  playit/  │
              │  nginx/{hosts,certs,custom}  logs/     │
              │  updates/{staging,backups}             │
              │                                        │
              │  NEVER overwritten by updates          │
              │  (see CLAUDE.md §1)                    │
              └────────────────────────────────────────┘

Documentation

• CLAUDE.md — rules for contributors (and AI assistants) on writing updates that don't break user data
• docs/ARCHITECTURE.md — system design overview
• docs/UPDATE_RULES.md — detailed update-safety rules
• docs/CLOUDFLARE_SETUP.md — how to create the Cloudflare API token
• docs/HOME-ASSISTANT.md — fixing Home Assistant's "400: Bad Request" behind a tunnel
• docs/STORE_PUBLISHING.md — how CloudGate reaches homelab app stores
• docs/AGENT.md — API keys and REST recipes for scripting/AI-agent use

Branch Strategy

• main — release-only. Tagged versions v0.x.y trigger GitHub Releases + GHCR image builds.
• dev — active development. All feature work goes here first.
• Feature branches → PR into dev → CI must pass.
• Periodic merges dev → main produce releases.

Contributing

PRs welcome. Read CLAUDE.md first — especially the persistence and migration rules. See docs/CONTRIBUTING.md for the dev workflow.
