Unraid

Tested against Unraid 7.x. bawksync runs as a normal Docker container, with its data in /mnt/user/appdata/bawksync.

There are two ways to add it: with the ready-made template (quicker), or by hand.

Option A: with the template

1. Open a terminal on Unraid: the >_ icon at the top right of the web UI.

2. Download the template into your user templates folder:

   wget -O /boot/config/plugins/dockerMan/templates-user/my-bawksync.xml \
     https://raw.githubusercontent.com/juddisjudd/bawksync/main/unraid/bawksync.xml


3. Go to the Docker tab and choose Add Container.

4. In the Template drop-down, under User templates, choose bawksync. The fields fill in.

5. Leave Token empty to have one created for you, or paste your own.

6. Choose Apply.

Then get your token.

Option B: by hand

1. Go to the Docker tab and choose Add Container.

2. Fill in:

   Field	Value
   Name	bawksync
   Repository	ghcr.io/juddisjudd/bawksync:latest
   Network Type	Bridge
   Console shell command	Shell

3. Choose Add another Path, Port, Variable, Label or Device and add a Port:

   • Name: Sync port
   • Container Port: 8787
   • Host Port: 8787
   • Connection Type: TCP

4. Add a Path:

   • Name: Data
   • Container Path: /data
   • Host Path: /mnt/user/appdata/bawksync
   • Access Mode: Read/Write

5. Add a Variable: Name PUID, Key PUID, Value 99.

6. Add a Variable: Name PGID, Key PGID, Value 100.

7. Choose Apply.

Unraid saves this as a user template, so you can edit it later from the container's icon → Edit.

Get your token

1. On the Docker tab, click the bawksync icon and choose Logs.
2. Copy the token printed after created a sync token.

The log line appears only on the first start. To show the token again later, open the container's Console and run bawksync tokens. It is also saved in /mnt/user/appdata/bawksync/tokens.

Connect

• At home: use http://<unraid-ip>:8787 in bawkterm, for example http://192.168.1.20:8787. See Connect bawkterm.

• Away from home: Unraid 7 can put the container on your Tailscale network directly:

  1. Install the Tailscale plugin from the Apps tab and sign in.
  2. Edit the bawksync container and turn on Use Tailscale. This needs the Bridge or a custom network.
  3. Use the container's Tailscale address in bawkterm.

  The other options on Remote access work too.

Updating and backups

• Update: the Docker tab shows update ready when a new image is out. Choose apply update.
• Back up: the Appdata Backup plugin (from Apps) backs up /mnt/user/appdata/bawksync on a schedule, stopping the container while it copies.

See Backups and updates.

Notes

• PUID=99 and PGID=100 are Unraid's usual nobody and users. The container fixes the data folder's ownership on start, then runs as that user.
• bawksync has no web page. http://<unraid-ip>:8787/v1/health shows a short status message if it's running.
